MSI PRO Z690-A

Original price was: $89.99.Current price is: $84.99.

(8 customer reviews)
Last updated on April 2, 2025 5:00 pm
0
Add to compare

Highest Price
$94.99 Newegg.com
January 2, 2025
Lowest Price
$84.99 Newegg.com
April 2, 2025
Current Price
$84.99 Newegg.com
April 2, 2025
Since October 19, 2024
This site uses affiliate links. We may earn a commission at no cost to you.
Prices and details are subject to change; check the seller’s site for updates.

Didn't find the right price? Set price alert below

Set Alert for Product: MSI PRO Z690-A DDR4 Intel LGA 1700 Motherboard - $84.99

Specification: MSI PRO Z690-A

Product
Brand

Model

PRO Z690-A WIFI DDR4

Product Type

Intel

Specification
Best Seller Ranking

#11 in Intel Motherboards

SATA RAID

0/1/5/10

Features

Supports 12th Gen Intel Core, Pentium Gold and Celeron processors for LGA 1700 socketSupports DDR4 Memory, up to 5200+(OC) MHzLightning Fast Experience: PCIe 5.0 slots, Lightning Gen4 x4 M.2, USB 3.2 Gen 2x2Premium Thermal Solution: Extended Heatsink Design, MOSFET thermal pads rated for 7W/mk and M.2 Shield Frozr are built for high performance system and non-stop works2.5G LAN with LAN Manager and Intel Wi-Fi 6 Solution: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connectionIntel Turbo USB 3.2 Gen 2: Powered by Intel USB 3.2 Gen2 controller, Turbo USB ensures an uninterrupted connection with more stability and fastest USB speedsAudio Boost: Reward your ears with studio grade sound qualityHigh Quality PCB: 6-layer PCB made by 2oz thickened copper and server grade level materialMulti-GPU: With Steel armor PCI-E slots. Supports AMD Crossfire

Windows 11

Supported

Power Pin

1 x 24-pin ATX main power connector2 x 8-pin ATX 12V power connector

Dimensions W x L

12.0" x 9.6"

LED Lighting

RGB

Form Factor

ATX

Audio Chipset

Realtek ALC897

Onboard USB

1 x USB 3.2 Gen 2 10Gbps Type-C port2 x USB 3.2 Gen 1 5Gbps connectors (supports additional 4 USB 3.2 Gen 1 5Gbps ports)2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)

Back IO Ports

1 x DisplayPort1 x HDMI1 x Flash BIOS Button1 x LAN (RJ45)2 x Antenna Bracket6 x Audio Jacks1 x PS/2 Keyboard/Mouse Combo1 x USB 3.2 Gen 2×2 Type-C1 x USB 3.2 Gen 2 Type-A2 x USB 3.2 Gen 1 Type-A4 x USB 2.0/1.1

Bluetooth

Bluetooth 5.2

Wireless LAN

Intel WIFI 6802.11 a/b/g/n/ac/ax

Max LAN Speed

10/100/1000/2500Mbps

LAN Chipset

Intel I225-V

Audio Channels

7.1 Channels

Other Connectors

1 x 4-pin CPU fan connector1 x 4-pin water-pump fan connector6 x 4-pin system fan connectors1 x Front panel audio connector2 x System panel connectors1 x Chassis Intrusion connector1 x Clear CMOS jumper1 x TPM module connector1 x Tuning controller connector1 x TBT connector (Supports RTD3)1 x 4-pin RGB LED connector2 x 3-pin RAINBOW LED connectors4 x EZ Debug LED

Intel Optane Ready

Intel Optane Memory Ready for M.2 slots that are from Z690 Chipset

Date First Available

March 20, 2022

Chipset

Intel Z690

Onboard Video Chipset

Supported only by CPU with integrated graphic

Number of Memory Slots

4x288pin (DDR4)

Memory Standard

2666, 2933, DDR4 1R 3200

Channel Supported

Dual Channel

PCI Express 5.0 x16

1 x PCI Express 5.0 x16* Actual support may vary by CPU.

PCI Express 3.0 x16

2 x PCI Express 3.0 x16* Supports up to PCIe 3.0 x4 & 3.0 x1

PCI Express x1

1 x PCI Express 3.0 x1

SATA 6Gbs

6 x SATA 6Gb/s

M.2

4 x M.2 slots (Key M):M2_1 slot (from CPU):Supports up to PCIe 4.0 x4Supports 2242, 2260, 2280, 22110 storage devicesM2_2 slot (from Z690 chipset):Support up to PCIe 4.0 x4Supports 2242, 2260, 2280 storage devicesM2_3 slot (from Z690 chipset):Support up to PCIe 3.0 x4Supports SATA 6Gb/sSupports 2242, 2260, 2280 storage devicesM2_4 slot (from Z690 chipset):Support up to PCIe 4.0x4Supports SATA 6Gb/sSupports 2242, 2260, 2280 storage devices

Max Memory Supported

128GB

CPU Socket

LGA 1700* Dedicated LGA1700 mounting bracket is required.

CPU Support

Celeron Processors* Please go to intel.com for compatibility information., Pentium Gold, Supports 12th Gen Intel Core

Photos: MSI PRO Z690-A

8 reviews for MSI PRO Z690-A

4.9 out of 5
7
1
0
0
0
Write a review
Show all Most Helpful Highest Rating Lowest Rating
  1. Curtis

    Pros: It posted Stays cool Needs bios update I hope Cons: This a weird issue I’m having every time I put the computer to sleep and try to wake it I get a ez debug light on the cpu thats flashes twice and then stays lit. One of the cpu fans will continue to spin while the other fan stops completely. If I restart the system boots up fine no issues. Just cant wake from sleep. I talked to msi and they said that this is an issue that can be fixed through a bios update so I will patiently wait….

    Helpful(0) Unhelpful(0)You have already voted this
  2. Austin R.

    Pros: It Posted with no issues. It OCs well and the vrms stay very cool. It also has all the important features without any of the bling which is a bonus for me. Cons: The is a strange issue where if you put your computer to sleep and wake it back up you get a cpu debug light and it wont turn on until you restart the computer. Also, there is no option in BIOS to disable the E cores. Overall Review: This motherboard has a great vrm, great feature set, and no RGB which is a bonus for me.

    Helpful(0) Unhelpful(0)You have already voted this
  3. Serban V.

    Pros: The board has a very good set of features, – 4 M.2 Slots It also comes with some little m.2 clips which are nice because you don’t need to screw the m.2 ssd in. – 6 Sata Ports – Wifi 6 – 1 PCIE 16x 5.0 There’s no real consumer uses for 5.0 yet but potentially could be useful in the future. – 2 PCIE 16x 3.0 – 6x Audio Jacks The motherboard’s power delivery for my 12700kf has been perfect. I do not think a 12900k maxed out would have any issue either but I’m not able to test that. The…

    Helpful(0) Unhelpful(0)You have already voted this
  4. Xuehao Z.

    Pros: 1. Double the M.2 slots (four total) compared to previous motherboards (Z490 and earlier only had two), this is huge as M.2 is becoming main stream 2. Eight 4-pin fan headers is more than generous. 3. MSI BIOS is easy to work with, also MSI has the best fan settings among major brands. It’s so easy to select each fan and corresponding temperature source, then choose between PWM and DC mode, and set your own fan curve or run at fixed speed. This is way better than ASUS and ASRock’s…

    Helpful(0) Unhelpful(0)You have already voted this
  5. leSourCil

    Pros: – Great price – Great feature – Wifi / Bluetooth 5 Cons: – No optical for sound I’m having an issue using both onbard graphic card and pcie gpu at the sametime not showing boot until arriving in windows, but to be honest it’s probably an option somewhere in the bios that i couldn’t find. Overall Review: I would recommand it easily. Worked out of the box. Thx MSI.

    Helpful(0) Unhelpful(0)You have already voted this
  6. Jiachen Zhou

    Pros: Great value, the price is reasonable. This motherboard can fit 12 gen Intel CPU perfectly. It does the basic job. Cons: I have a big cooling fan so it cannot perfectly fit into this motherboard, it would be installed on top of the DDR4 slots. Also, the manual is hard to follow so I use an online tutorial video for reference. Overall Review: This review is for the MSI Review Rebate Program. I would recommend buying this motherboard because it does most of the jobs, and the price is…

    Helpful(0) Unhelpful(0)You have already voted this
  7. Roy t.

    Pros: Simple and effective Cons: As soon as you finish installing windows , msi center jumps on you with a full nelson choke Overall Review: I guess the hype was justified gg msi

    Helpful(0) Unhelpful(0)You have already voted this
  8. MegaSkrunch

    Pros: – lots of space – no RGB – easy to set up – lots of VRM Cons: – at my time of purchase the mobo did not ship with any network drivers installed, I had to install them from a USB drive after installing the OS – newest non-beta BIOS does not have good support for XMP profiles/RAM, although XMP is enabled my RAM speed in benchmarks is not what BIOS has listed – IO shields are the worst Overall Review: Overall I would recommend this motherboard if you want a minimal design. It will only…

    Helpful(0) Unhelpful(0)You have already voted this
