- 10%

GIGABYTE B550M DS3H

Original price was: $109.99.Current price is: $98.99.

(8 customer reviews)
Last updated on October 19, 2024 7:05 pm
0
Add to compare

Highest Price
$126.04 Walmart.com
May 15, 2024
Lowest Price
$75.00 eBay
November 8, 2024
Current Price
$98.99 Amazon.com
October 19, 2024
Since May 11, 2024

Didn't find the right price? Set price alert below

Set Alert for Product: GIGABYTE B550M DS3H (AM4 AMD/B550/Micro ATX/Dual M.2/SATA 6Gb/s/USB 3.2 Gen 1/PCIe 4.0/HMDI/DVI/DDR4/Motherboard) - $98.99

Specification: GIGABYTE B550M DS3H

Product
Brand

Model

B550M DS3H

Series

DDR4

Product Type
Type

AMD

Specification
Best Seller Ranking

#9 in AMD Motherboards

SATA RAID

0/1/10

Features

I/O Controller:iTE I/O Controller ChipH/W Monitoring:Voltage detectionTemperature detectionFan speed detectionOverheating warningFan fail warningFan speed control* Whether the fan speed control function is supported will depend on the cooler you install.BIOS:1 x 256 Mbit flashUse of licensed AMI UEFI BIOSPnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0Unique Features:Support for APP Center* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.@BIOSEasyTuneFast BootGame BoostON/OFF ChargeRGB FusionSmart BackupSystem Information ViewerSupport for Q-Flash PlusSupport for Q-FlashSupport for Xpress InstallBundled Software:Norton Internet Security (OEM version)Realtek 8118 Gaming LAN Bandwidth Control UtilityOperating System:Support for Windows 10 64-bit

Windows 11

Supported

Power Pin

1 x 24-pin ATX main power connector1 x 8-pin ATX 12V power connector

Dimensions W x L

9.6" x 9.6"

LED Lighting

RGB

Form Factor

Micro ATX

Other Connectors

1 x CPU fan header2 x system fan headers2 x addressable LED strip headers2 x RGB LED strip headers1 x CPU cooler LED strip/RGB LED strip header1 x front panel header1 x front panel audio header1 x Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only)1 x serial port header1 x Clear CMOS jumper1 x Q-Flash Plus button

Onboard USB

1 x USB 3.2 Gen 1 header1 x USB 2.0/1.1 header

Back IO Ports

1 x PS/2 keyboard/mouse port1 x DVI-D port1 x HDMI port4 x USB 3.2 Gen 1 ports4 x USB 2.0/1.1 ports1 x RJ-45 port3 x audio jacks

Max LAN Speed

10/100/1000Mbps

LAN Chipset

Realtek GbE LAN chip

Audio Channels

2/4/5.1/7.1-channel* To configure 7.1-channel audio

Audio Chipset

Realtek ALC887

Onboard Video Chipset

Integrated in the 3rd Generation AMD Ryzen with Radeon Graphics processors:1 x DVI-D port, supporting a maximum resolution of 1920×1200@60 Hz* The DVI-D port does not support D-Sub connection by adapter.1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz* Support for HDMI 2.1 version, HDCP 2.3, and HDR.Maximum shared memory of 16GB

M.2

1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs:3rd Generation AMD Ryzen processors support SATA and PCIe 4.0 x4/x2 SSDs3rd Generation AMD Ryzen with Radeon Graphics processors support SATA and PCIe 3.0 x4/x2 SSDs1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2242/2260/2280 SSDs:Supporting SATA and PCIe 3.0 x2 SSDs

SATA 6Gbs

4 x SATA 6Gb/s

PCI Express x1

1 x PCI Express x1 slot (PCIEX1), integrated in the Chipset:Supporting PCIe 3.0 x1 mode

PCI Express 3.0 x16

1 x PCI Express x16 slot (PCIEX4), integrated in the Chipset:Supporting PCIe 3.0 x4 mode

PCI Express 4.0 x16

1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:3rd Generation AMD Ryzen processors support PCIe 4.0 x16 mode3rd Generation AMD Ryzen with Radeon Graphics processors support PCIe 3.0 x16 mode* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.

Channel Supported

Dual Channel

Memory Standard

2133 MHz memory modules, 2133 MHz memory modulesNew Generation AMD Ryzen with Radeon Graphics processors:Support for DDR4 4733(O.C.), 2400, 2667, 2933, 3200, 3333(O.C.), 3600(O.C.), 3rd Gen AMD Ryzen Processors:Support for DDR4 4000(O.C.), 4000(O.C.), 4400(O.C), 4600(O.C)

Number of Memory Slots

4x288pin (DDR4)

Chipset

AMD B550

CPU Socket Type

AM4

Date First Available

June 15, 2020

CPU Type Support

3rd Gen Ryzen and 3rd Gen Ryzen with Radeon Graphics Processors* Support for Ryzen 5000 Series with BIOS UPDATE. Refer to GIGABYTE website for CPU support list., AMD Socket AM4, support for: AMD Ryzen 5000 Series

Max Memory Supported

128GB

Photos: GIGABYTE B550M DS3H

8 reviews for GIGABYTE B550M DS3H

3.8 out of 5
4
2
0
0
2
Write a review
Show all Most Helpful Highest Rating Lowest Rating
  1. Caleb S.

    Overall Review: I bought an AMD RYZEN 5 3600 CPU and this MOBO at the same time, and both worked right out of the box. I will say it is very hard to use one of the SATA ports if you have a large video card, but it can be done if you use 90 degree-bend SATA cables.

    Helpful(0) Unhelpful(0)You have already voted this
  2. Anonymous

    Pros: Motherboard is of good quality. Has 4 memory slots, sufficient pci-e, two m.2 Cons: The two PCIex16 and the PCIex4 are VERY close together. If you have a large Graphic card, you will lose a PCIex16, a PCIex4 and a m.2 by attaching your graphic card. Overall Review: Good quality and did work

    Helpful(0) Unhelpful(0)You have already voted this
  3. Anonymous

    Pros: This board came ready to go with my ryzen 3600 CPU amazing motherboard.easy set up I love the dual M.2 slots. Easy to set up bios and it has the flash bios update so you don’t need a last generation Cpu.you can flash bios by usb. Overall Review: This board came ready to go with my ryzen 3600 CPU amazing motherboard.easy set up I love the dual M.2 slots.

    Helpful(0) Unhelpful(0)You have already voted this
  4. Nathaniel D.

    Pros: Great motherboard that I can continue to use in my setup for long time I’m sure Cons: BUY FAN CABLE SPLITTERS, this mother board has 2 system fan plugins which was definitely not enough fans for your case alone. if you plan to use fans that plug directly into the power supply though you should be perfectly fine without them. Overall Review: Great purchase, worked perfectly with my Amd Ryzen 5 3600 straight out the box. Pc booted up first go.

    Helpful(0) Unhelpful(0)You have already voted this
  5. Anonymous

    Pros: – Nice compact mobo – No compatibility issues with Ryzen 5 3600 – Gigabyte Software is fairly straightforward Cons: – SATA cables are super tight with a full sized GPU installed, 90° connectors are a must. At least one slot will remain inoperable without the proper cables – Full sized GPU’s will take up a ton of space on the board – Front panel connections took a bit to figure out – Some users have pointed out that the Wraith Cooler inteferes with the closest memory slot. A quick…

    Helpful(0) Unhelpful(0)You have already voted this
  6. Michael P.

    Overall Review: Mobo arrived doa wouldn’t get post. After swapping all components I determined my mobo was bad I sent it back to gigabyte they said it was fine and sent it back. I ordered a different brand 550 and when I received it hooked it all up an my pc then worked. I would not recommend gigabyte mobo this is my second one I’ve had issues with and poor customer support.

    Helpful(0) Unhelpful(0)You have already voted this
  7. Adam H

    Cons: Bought the board in August 2020 used for a month had a baby in September and didn’t touch the pc until end of February 2021 board has no power swapped the psu to a working psu still no power Overall Review: Worked great for the month I got to use it after 4 months of inactive board no longer powers on

    Helpful(0) Unhelpful(0)You have already voted this
  8. Trevor H.

    Pros: Worked with my Ryzen 5 5600g out of the box. Wicked BIOS, easy to use Price is very reasonable Looks great in my micro ATX case Cons: No sticker included!!! I’m a sucker for PC part stickers. Overall Review: My last Gigabyte mobo lasted 10 years without a hitch. Their boards have never let me down.

    Helpful(0) Unhelpful(0)You have already voted this
