ASUS ROG Strix Z690-I Gaming

$250.00

(8 customer reviews)
Last updated on February 16, 2025 1:09 pm
0
Add to compare

Highest Price
$192.83 Walmart.com
February 23, 2025
Lowest Price
$159.98 Walmart.com
November 28, 2024
Current Price
$250.00 Amazon.com
February 16, 2025
Since November 8, 2024
This site uses affiliate links. We may earn a commission at no cost to you.
Prices and details are subject to change; check the seller’s site for updates.

Didn't find the right price? Set price alert below

Set Alert for Product: ASUS ROG Strix Z690-I Gaming WiFi 6E LGA 1700 (Intel 12th Gen) mini-ITX gaming motherboard (PCIe 5.0,DDR5,Thunderbolt 4,2.5Gb LAN,USB 3.2 Gen 2x2 front panel Type-C,2x M.2,bundled ITX expansion card) - $250.00

Specification: ASUS ROG Strix Z690-I Gaming

Product
Brand

Model

STRIX Z690-I GAMING WIFI

Product Type

Intel

Specification
Best Seller Ranking

#65 in Intel Motherboards

Form Factor

Mini ITX

Audio Channels

7.1 Channels

Max LAN Speed

10/100/1000/2500Mbps

Wireless LAN

Wi-Fi 6E802.11 a/b/g/n/ac/ax

Bluetooth

Bluetooth 5.2

Back IO Ports

2 x Thunderbolt 4 USB Type-C port(s)2 x USB 3.2 Gen 2 port(s) (2 x Type-A)3 x USB 3.2 Gen 1 port(s) (3 x Type-A)2 x USB 2.0 port(s) (2 x Type-A) 1 x HDMI port1 x Wi-Fi Module1 x Intel 2.5Gb Ethernet portLED-illuminated audio jacks1 x Optical S/PDIF out port1 x BIOS FlashBack button 1 x Clear CMOS button

Onboard USB

1 x USB 3.2 Gen 2×2 connector (support(s) USB Type-C) 1 x USB 3.2 Gen 1 header(s) support(s) additional 2 USB 3.2 Gen 1 ports1 x USB 2.0 header(s) support(s) additional 2 USB 2.0 ports2 x USB Type-C connectors to Install ROG Strix Front panel SATA card** Install ROG Strix Front panel SATA card to support 4 x SATA 6Gb/s ports, 1 x Addressable Gen 2 header, 1 x Front Panel header and 1 x Speaker header.

SATA RAID

0/1/5/10

Other Connectors

Fan and Cooling related 1 x 4-pin CPU Fan header(s)1 x 4-pin AIO Pump header(s)1 x 4-pin Chassis Fan header(s)Miscellaneous1 x Addressable Gen 2 header(s)1 x AURA RGB header(s)1 x 2 pin POWER_BTN header

LED Lighting

RGB

Dimensions W x L

6.7" x 6.7"

Power Pin

1 x 24-pin Main Power connector1 x 8-pin +12V Power connector

Windows 11

Ready

Features

Special Features:Extreme Engine Digi+- 5K Black Metallic Capacitors ASUS Q-Design – M.2 Q-Latch- Q-DIMM- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])- Q-SlotASUS Thermal Solution- M.2 heatsink backplate- M.2 heatsink ASUS EZ DIY- BIOS FlashBack button- BIOS FlashBack LED- Clear CMOS button- CPU Socket lever protector- ProCool II- Pre-mounted I/O shield- SafeSlot- SafeDIMMAURA Sync- AURA RGB header(s)- Addressable Gen 2 header(s)Software Features:ROG Exclusive Software- GameFirst VI- ROG CPU-Z- Sonic Studio III + Sonic Studio Virtual Mixer + Sonic Suite Companion- Sonic Radar III- DTS Sound Unbound – Anti-virus softwareASUS Exclusive SoftwareArmoury Crate- AIDA64 Extreme (60 days free trial) – AURA Creator- AURA Sync- Fan Xpert 4 – Two-Way AI Noise CancelationAI Suite 3- 5-Way Optimization with AI OverclockingTPU EPU DIGI+ VRMFan Xpert 4 Turbo appMyAsusWinRARUEFI BIOSAI Overclocking GuideASUS EZ DIY – ASUS CrashFree BIOS 3 – ASUS EZ Flash 3 – ASUS UEFI BIOS EZ ModeFlexKeyMemTest86BIOS:256 Mb Flash ROM, UEFI AMI BIOSManageability:WOL by PME, PXE Operating System:Windows 11 64-bit, Windows 10 64-bit

Package Contents

Accessories:Cables1 x ROG USB2.0 splitter cable1 x Panel Cable2 x SATA 6Gb/s cables Miscellaneous1 x ASUS Wi-Fi moving antennas 1 x Cable ties pack1 x M.2 Q-Latch package(s)1 x ROG key chain1 x ROG logo plate stickers1 x ROG Strix stickers 1 x ROG Strix thank you cardInstallation Media1 x Support DVDDocumentation1 x User guide

Audio Chipset

ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080

Chipset

Intel Z690

M.2

Intel 12th Gen Processors:M.2_1 slot (Key M), type 2242/2260/2280- Intel 12th Gen processors support PCIe 4.0 x4 mode. Intel Z690 Chipset:M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes)

SATA 6Gbs

4 x SATA 6Gb/s* Install ROG Strix Front panel SATA card to support 4 x SATA 6Gb/s ports.

PCI Express 5.0 x16

1 x PCI Express 5.0 x16* Actual support may vary by CPU.

Channel Supported

Dual Channel

Memory Standard

4800(OC)** Actual Memory frequency support depends on the CPU types and DRAM modules, 5000(OC), 5200(OC), 5400(OC), 5600(OC), 5800(OC), 6000(OC), 6200(OC), DDR5 6400(OC), for more information refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).

Number of Memory Slots

2x288pin (DDR5)

Onboard Video Chipset

Supported only by CPU with integrated graphic

Supported CPU Technologies

Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0** Intel Turbo Boost Max Technology 3.0 support depends on the CPU types.

Part Number

90MB1910-M0AAY0

Series

ROG

Date First Available

October 27, 2021

Max Memory Supported

64GB

CPU Socket

LGA 1700* Designed with dual mounting holes compatible with both Intel LGA1700 and LGA1200 cooling brackets.

CPU Support

Celeron Processors* Refer to www.asus.com for CPU support list., Pentium Gold, Supports 12th Gen Intel Core

Photos: ASUS ROG Strix Z690-I Gaming

8 reviews for ASUS ROG Strix Z690-I Gaming

4.1 out of 5
5
0
2
1
0
Write a review
Show all Most Helpful Highest Rating Lowest Rating
  1. El Narnia

    Pros: Bracket LGA 1200 fit without issues Cons: EK AIO not fit in this board. I replaced it with a Corsair that its sleeves are a little smaller and it works very well! Overall Review: Recommended

    Helpful(0) Unhelpful(0)You have already voted this
  2. Ronald A.

    Overall Review: When installing a 980 pro to the top M2 slot there is a gap between it and the bottom thermal pad. When adding the cover it bends the drive into the gap. I have fixed it with a thinner thermal pad on the cover and used small plastic washers to raise the bottom bracket up.

    Helpful(0) Unhelpful(0)You have already voted this
  3. Anonymous

    Pros: High end board Cons: Stacked M.2 Slots Overall Review: Check the clearance under the CPU socket when building in a SFF case. I tried to put this in an H1 and it would not close because the radiator fan collided with the stacked M.2 heatsink.

    Helpful(0) Unhelpful(0)You have already voted this
  4. yyc

    Overall Review: When installing a sn850 to the top m.2 slot there is a gap between it and the bottom thermal pad. When adding the cover it bends the drive into the gap. I have fixed it with a thinner thermal pad on the cover and used small paper to raise the bottom bracket up.

    Helpful(0) Unhelpful(0)You have already voted this
  5. Jason L.

    Pros: It’s a nice board. Specs, build, features, etc. I would write more if I was able to use it long enough to find out. Cons: Cannot keep the computer on for more than a few hours at most. Constant issues with my G.Skill DDR5 5600 36-36-36-76 RAM. Newest BIOS upgrade to 0811 made it more unstable than the previous. XMP on or off, doesn’t matter, differen’t BSODs that all revolve around RAM occur. Overall Review: Of all the computers I’ve ever built, this is what I get for being an early…

    Helpful(0) Unhelpful(0)You have already voted this
  6. Satonmyass

    Pros: Quality, Connectivity, Onboard Connectors Cons: A little pricey Overall Review: I never post reviews in things I buy, but I noticed that the top review for this board states it does not fit the NZXT H1. So I needed to chime in to make sure that comment wasnt going to deter anyone from buying this board for the H1. Dont get me wrong, the fit is very tight, but not so much so anything is strained or squished. As commented on the other review, while you are closing up the radiator panel,…

    Helpful(0) Unhelpful(0)You have already voted this
  7. Andrew T.

    Pros: Everything just worked right out of the box. 12900k Corsair Vengeance DDR5 5600mhz. Squeezed this build into a Phanteks Eclipse 200p ITX case. Plenty of room. EVGA SuperNova 1000w gold power supply, ASUS RTX 2070 dual mini graphics card. Arctic liquid freezer ii 280 cooler. VRM Fan built in Cons: None really. would have been nice to have a 3rd m.2 slot or even pcie5 on the m.2 lanes but i guess that will have to wait till next gen. Overall Review: It’s pricey but worth the money in my…

    Helpful(0) Unhelpful(0)You have already voted this
  8. Leonard A.

    Pros: This was a motherboard for a Silverstone RVZ03 case. By the time I was finished, it had two Samsung 980 NVME memory cards, a 12 Generation I7 Processor with a Noctua fan and heatsink. and an MSI 1650 video card. It was crammed so full of high tech stuff, I didn’t think it would boot. My bad, the Corsair 750 watt power supply didn’t even bat an eye and it fired right up. It is one of the cutest computer builds I’ve ever done, and it ROCKS! After I convinced the Intel drivers to load,…

    Helpful(0) Unhelpful(0)You have already voted this
