ASUS ROG Strix Z690-E Gaming

Original price was: $279.99.Current price is: $230.99.

(8 customer reviews)
Last updated on February 16, 2025 3:50 pm
0
Add to compare

Highest Price
$275.00 Walmart.com
February 16, 2025
Lowest Price
$230.99 Amazon.com
February 23, 2025
Current Price
$230.99 Amazon.com
February 16, 2025
Since September 9, 2024
This site uses affiliate links. We may earn a commission at no cost to you.
Prices and details are subject to change; check the seller’s site for updates.

Didn't find the right price? Set price alert below

Set Alert for Product: ASUS ROG Strix Z690-E Gaming WiFi 6E LGA 1700(Intel 12th Gen)ATX gaming motherboard(PCIe 5.0,DDR5,2.5 Gb LAN,Thunderbolt 4,5xM.2,1xPCIe 5.0 M.2,ROG Hyper M.2 Card,Front panel USB 3.2 Gen 2x2 Type-C) - $230.99

Specification: ASUS ROG Strix Z690-E Gaming

Product
Brand

Model

STRIX Z690-E GAMING WIFI

Product Type

Intel

Specification
Best Seller Ranking

#7 in Intel Motherboards

Intel Optane Ready

Yes

Audio Chipset

ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080

Audio Channels

7.1 Channels

LAN Chipset

Intel I225-V

Max LAN Speed

10/100/1000/2500Mbps

Wireless LAN

Wi-Fi 6E802.11 a/b/g/n/ac/ax

Bluetooth

Bluetooth 5.2

Back IO Ports

1 x USB 3.2 Gen 2×2 port (1 x USB Type-C)3 x USB 3.2 Gen 2 ports (2 x Type-A, 1 x USB Type-C )4 x USB 3.2 Gen 1 ports (4 x Type-A)4 x USB 2.0 ports (2 x Type-A) 1 x HDMI port1 x DisplayPort1 x Wi-Fi Module1 x Intel I225-V 2.5Gb Ethernet5 x Gold-plated audio jacks1 x Optical S/PDIF out port1 x BIOS FlashBack button 1 x Clear CMOS button

SATA RAID

0/1/5/10

Onboard USB

1 x USB 3.2 Gen 2×2 connector (supports USB Type-C) 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports2 x USB 2.0 headers support additional 4 USB 2.0 ports

Form Factor

ATX

LED Lighting

RGB

Dimensions W x L

12.0" x 9.6"

Power Pin

1 x 24-pin Main Power connector2 x 8-pin +12V Power connector

Windows 11

Ready

Features

Special Features:Extreme Engine Digi+- 5K Black Metallic CapacitorsASUS Q-Design – M.2 Q-Latch- PCIe Slot Q-Release- Q-DIMM- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])- Q-SlotASUS Thermal Solution- M.2 heatsink backplate- M.2 heatsinkASUS EZ DIY- BIOS FlashBack button- BIOS FlashBack LED- Clear CMOS button- CPU Socket lever protector- ProCool II- Pre-mounted I/O shield- SafeSlot- SafeDIMMAURA Sync- AURA RGB header- Addressable Gen 2 RGB headersASUS HYDRANODE- 1 x Chassis fan support* (CHA_FAN1P)* Visit ASUS Website for the latest compatibility list.TPM headerSoftware Features:ROG Exclusive Software- ROG CPU-Z- GameFirst VI- Sonic Studio III + Sonic Studio Virtual Mixer + Sonic Suite Companion- Sonic Radar III- DTS Sound Unbound – Anti-virus softwareASUS Exclusive SoftwareArmoury Crate- AIDA64 Extreme (60 days free trial)- AURA Creator- AURA Sync- Fan Xpert 4 – Two-Way AI Noise CancelationAI Suite 3- 5-Way Optimization with AI OverclockingTPUEPU DIGI+ VRMTurbo appMyAsusWinRARUEFI BIOSAI Overclocking GuideASUS EZ DIY – ASUS CrashFree BIOS 3 – ASUS EZ Flash 3 – ASUS UEFI BIOS EZ ModeFlexKeyMemTest86BIOS:256 Mb Flash ROM, UEFI AMI BIOSManageability:WOL by PME, PXE Operating System:Windows 10 64-bit, Windows 11 64-bit

Package Contents

Accessories:Cables4 x SATA 6Gb/s cables ROG HYPER M.2 CARD1 x ROG HYPER M.2 CARD Miscellaneous1 x ASUS 2×2 Dual-Band Wi-Fi moving antennas 1 x M.2 Q-Latch package 1 x M.2 Q-Latch package for M.2 backplate1 x M.2 Rubber Packages2 x M.2 Screw Packages1 x ROG Graphics card holder1 x ROG key chain1 x cable tie1 x ROG STRIX stickers1 x ROG STRIX thank you cardInstallation Media1 x Support DVDDocumentation1 x User manual

Other Connectors

Fan and Cooling related 1 x 4-pin CPU Fan header1 x 4-pin CPU OPT Fan header1 x 4-pin AIO Pump header5 x 4-pin Chassis Fan headersMiscellaneous3 x Addressable Gen 2 headers1 x AURA RGB header1 x CPU Over Voltage jumper1 x Front Panel Audio header (AAFP) 1 x SPI TPM header (14-1pin)1 x 20-3 pin System Panel header with Chassis intrude function1 x Thermal Sensor header1 x Thunderbolt header

M.2

Intel 12th Gen Processors:M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)- Intel 12th Gen processors support PCIe 5.0 x4 mode.M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)- Intel 12th Gen processors support PCIe 4.0 x4 mode.Hyper M.2_1 slot (Key M) via Hyper M.2 card, type 2242/2260/2280/22110**- Intel 12th Gen processors support PCIe 4.0 x4 modeIntel Z690 Chipset:*M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode & SATA modes)Hyper M.2_1 slot (Key M) via Hyper M.2 card, type 2242/2260/2280/22110 (suppports PCIe 4.0 x4 mode)***Hyper M.2_2 slot (Key M) via Hyper M.2 card, type 2242/2260/2280/22110 (suppports PCIe 4.0 x4 mode)**** Intel Rapid Storage Technology supports Intel Optane Memory H Series on PCH attached M.2 slots.** When ROG Hyper M.2 card is installed on PCIEX16(G5), only Hyper M.2_1 slot can support PCIe 4.0 x4 mode. When ROG Hyper M.2 card is installed on PCIEX16(G3), only Hyper M.2_1 slot can support PCIe 3.0 x4 mode. When ROG Hyper M.2 card is installed on PCIEX16(G4), Hyper M.2_1 and Hyper M.2_2 slots can support PCIe 4.0 x4 mode.*** When ROG Hyper M.2 card is installed on PCIEX16(G5) or PCIEX16(G3), Hyper M.2_2 slot will be disabled. When ROG Hyper M.2 card is installed on PCIEX16(G4), Hyper M.2_1 and Hyper M.2_2 slots can support PCIe 4.0 x4 mode.

Number of Memory Slots

4x288pin (DDR5)

SATA 6Gbs

6 x SATA 6Gb/s* RAID configuration and boot drives are not supported on the SATA6G_E1-2 ports.

Series

ROG

Part Number

90MB18J0-M0AAY0

Supported CPU Technologies

Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0** Intel Turbo Boost Max Technology 3.0 support depends on the CPU types.

Chipset

Intel Z690

Onboard Video Chipset

Supported only by CPU with integrated graphic

Memory Standard

4800 * Supported memory types, 5000(OC), 5200(OC), 5400(OC), 5600(OC), 5800(OC), 6000(OC), 6200(OC), and number of DRAM module vary depending on the CPU and memory configuration, data rate(Speed), DDR5 6400(OC), for more information refer to www.asus.com for memory support list.

Channel Supported

Dual Channel

PCI Express 5.0 x16

1 x PCI Express 5.0 x16* Actual support may vary by CPU.* When M.2_1 is occupied with SSD device, PCIEX16(G5) will run x8 only.

PCI Express 4.0 x16

1 x PCI Express 4.0 x16* Supports x4 mode or x4/x4 mode for ROG HYPER M.2 CARD.

PCI Express 3.0 x16

1 x PCI Express 3.0 x16* Supports x4 mode.

PCI Express x1

1 x PCIe 3.0 x1

Date First Available

October 27, 2021

Max Memory Supported

128GB

CPU Socket

LGA 1700* Designed with dual mounting holes compatible with both Intel LGA1700 and LGA1200 cooling brackets.

CPU Support

Celeron (12th Gen, Core, LGA1700), Pentium

Photos: ASUS ROG Strix Z690-E Gaming

8 reviews for ASUS ROG Strix Z690-E Gaming

5.0 out of 5
8
0
0
0
0
Write a review
Show all Most Helpful Highest Rating Lowest Rating
  1. Theodore G.

    Pros: The AI overclocking tool is neat, bios has a million options. Cons: Probably should have gotten the Maximus Hero Overall Review: Overclocks a 12900k to 5.4ghz with a touch of a button. The VRM heatsink is beefy. The PCIe release button is neat. I like it, if the Maximus Hero board was available I probably would have sprung for that given theres not much of a difference in price, but this was the only one available at the time.

    Helpful(0) Unhelpful(0)You have already voted this
  2. Famorak

    Pros: Solid board. this is why i love Asus. works great out of the box! so many features packed into one board DDR5 M2 drive bay AI overclocking Cons: This is my 8th ASUS board i think. They never fail. nothing bad to say Overall Review: Only Brand I trust for motherboards!

    Helpful(0) Unhelpful(0)You have already voted this
  3. D. Reese

    Pros: Looks good in the tower!! Easy to setup and the instructions were well written. Got it up and running quick!! No issues with anything during the setup, size of the board in the case, or placement. Cons: None at this time. Overall Review: Yes, I would recommend.

    Helpful(0) Unhelpful(0)You have already voted this
  4. Anonymous

    Pros: Amazing bios Cons: Too much RGB Overall Review: I swapped from a ASUS ROG STRIX z590, the transition was painless even with keeping my original OS partition

    Helpful(0) Unhelpful(0)You have already voted this
  5. baZANNN

    Pros: Noob-friendly Great Performance Tons of settings and customization for the technically advanced. Cons: Price is still high, but it’s early adopter season when it comes to Alder Lake.. so it’s really not that surprising. Overall Review: This is my first experience with an Asus motherboard. For the most part I’ve usually stuck with MSI for their reliability, but I feel like their board lines continue to get super saturated. This board and it’s huge headroom for customization has been…

    Helpful(0) Unhelpful(0)You have already voted this
  6. Justin K.

    Overall Review: Had to RMA the first board and the return process with new egg was flawless, 5 stars for new egg!

    Helpful(0) Unhelpful(0)You have already voted this
  7. Archivist

    Pros: Works great Based on past experiences with Asus, this motherboard should last for years Cons: Price is high. If I average the cost out the years I will be using it, it not seem that bad at all. DDR5 is overpriced and is hard to find. Overall Review: Works great. Glad I purchased it. For the people that complain about coolers not fitting, etc. not that difficult to do some research on what will and will not work with it. Take a little time before purchasing is what should have been…

    Helpful(0) Unhelpful(0)You have already voted this
  8. Leon D.

    Pros: It’s a beautiful board with no issues, at least for me. Everything just works. I am running an i9-12900k Intel processor and 32gb Corsair Vengeance 4800MHz memory. I have had no issues with this board. Everything just works. Cons: It’s expensive. It has only one temperature header. Not a deal breaker. I have two temperature probes and no place to plug it in, my fault as I didn’t think about this. Overall Review: I would recommend this board but if on a tight budget there are alot of…

    Helpful(0) Unhelpful(0)You have already voted this
