ASUS ROG STRIX B550-F Gaming

Original price was: $209.99.Current price is: $99.99.

(8 customer reviews)
Last updated on July 16, 2025 2:23 am
0
Add to compare

Highest Price
$99.99 Walmart.com
July 27, 2025
Lowest Price
$99.99 Walmart.com
July 27, 2025
Current Price
$99.99 Walmart.com
July 16, 2025
Since July 27, 2025
This site uses affiliate links. We may earn a commission at no cost to you.
Prices and details are subject to change; check the seller’s site for updates.

Specification: ASUS ROG STRIX B550-F Gaming

Product
Brand

Model

STRIX B550-F GAMING

Product Type

AMD

Specification
Best Seller Ranking

#3 in AMD Motherboards

Other Connectors

1 x CPU Fan connector(s)1 x CPU OPT Fan connector(s)3 x Chassis Fan connector(s)1 x AIO_PUMP connector1 x AAFP connector2 x Aura RGB Strip Header(s)1 x Addressable Gen 2 header(s)1 x Thunderbolt header(s)1 x System panel(s)1 x Thermal sensor connector(s)1 x Clear CMOS jumper(s)

Audio Chipset

ROG SupremeFX High Definition Audio CODEC S1220A

Audio Channels

32-Bit/192kHz is not supported for 8-Channel audio., 8 Channels** Due to limitations in HDA bandwidth

LAN Chipset

Intel I225-V

Max LAN Speed

10/100/1000/2500Mbps

Back IO Ports

1 x Intel I225-V 2.5Gb Ethernet1 x DisplayPort1 x HDMI2 x USB 3.2 Gen 2 (1 x Type-A + 1 x USB Type-C)4 x USB 3.2 Gen 12 x USB 2.01 x Optical S/PDIF out1 x BIOS FlashBack Button(s)5 x Gold-plated audio jacks

Onboard USB

1 x USB 3.2 Gen 1 (up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s)2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)

Form Factor

ATX

SATA RAID

0/1/10

LED Lighting

RGB

Dimensions W x L

12.0" x 9.6"

Power Pin

1 x 24-pin EATX Power connector(s)1 x 8-pin ATX 12V Power connector(s)1 x 4-pin ATX 12V Power connector(s)

Windows 11

Supported

Features

Multi-GPU Support:Supports AMD 2-Way CrossFireX Technology Software Features:ROG Exclusive Software- RAMCache III- ROG CPU-Z- GameFirst VI- Sonic Studio III + Sonic Studio Virtual Mixer- Sonic Radar III- DTS Sound Unbound- Overwolf- Anti-virus softwareASUS Exclusive Software FeaturesArmoury Crate- Aura Creator- Aura Sync- AI Noise Cancelling MicrophoneAI Suite 3:- PPSUEPUDIGI+ VRMFan Xpert 4TurboV EVO- EZ updateWinRARUEFI BIOSASUS EZ DIY- ASUS CrashFree BIOS 3- ASUS EZ Flash 3- ASUS UEFI BIOS EZ ModeASUS Special Features:Aura Sync- Standard RGB header(s)- Addressable Gen 2 RGB header(s)ASUS Q-Design- ASUS Q-DIMM- ASUS Q-LED (DRAM [yellow], CPU [red], VGA [white], Boot Device [yellow green)- ASUS Q-SlotASUS Thermal Solution- Aluminum M.2 heatsinkASUS EZ DIY- BIOS FlashBack button- BIOS FlashBack LED- Clear CMOS header- ProCool- Pre-mounted I/O shield- SafeSlotBIOS:256MB Flash ROM, UEFI AMI BIOSManageability:WOL by PME, PXEOperating System:Windows 10 64-bit

Package Contents

Accessories:User's manual4 x SATA 6Gb/s cable(s)1 x Supporting DVD1 x ROG Strix stickers1 x Cable ties pack(s)1 x Extension cable for Addressable LED1 x ROG Thank you card1 x M.2 SSD screw package(s)1 x M.2 Rubber Package(s)

Onboard Video Chipset

Supported only by CPU with integrated graphic

M.2

3rd Gen AMD Ryzen Processors:1 x M.2_1 socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIe 4.0 x4 mode)AMD B550 Chipset:1 x M.2_2 socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x4 mode)** When the M.2_2 Socket 3 is populated, SATA6G_5/6 ports will be disabled.

Memory Standard

2133 (3rd Gen AMD Ryzen Processors)* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists)., 2133 (Next Generation AMD Ryzen PRO Processors)DDR4 4600(OC), 2400, 2666, 2800, 3000, 3200, 3466(OC), 3600(OC), 3866(OC), 4000(OC), 4133(OC), 4400(OC), 4600(OC), 4800(OC), 5000(OC), DDR4 5100(OC)

Series

ROG

Chipset

AMD B550

Number of Memory Slots

4x288pin (DDR4)

SATA 6Gbs

6 x SATA 6Gb/s

Channel Supported

Dual Channel

Buffer Supported

Un-buffered

PCI Express 4.0 x16

1 x PCI Express 4.0 x16** Actual support may vary by CPU.

PCI Express 3.0 x16

1 x PCIe 3.0 x16 (x4 mode)** Share bandwidth with PCIe3.0 x1_1, PCIe3.0 x1_2, PCIe3.0 x1_3.

PCI Express x1

3 x PCIe 3.0 x1

Date First Available

June 12, 2020

Max Memory Supported

128GB

CPU Socket

AM4

CPU Support

3000 Series Processors** BIOS update might require for AMD Zen 3 Ryzen 5000 series CPU. Refer to ASUS website for CPU support list., 4000 G-Series, Supports AMD Ryzen 5000 Series

ECC

Yes

Photos: ASUS ROG STRIX B550-F Gaming

8 reviews for ASUS ROG STRIX B550-F Gaming

3.4 out of 5
3
1
2
0
2
Write a review
Show all Most Helpful Highest Rating Lowest Rating
  1. Rafael B.

    Pros: lighting, quality, nice features, I swapped from a b450-f strix, now my fans light up thanks to the argb header on this motherboard Cons: only thing i had issue with was enable CSM in bios to boot into windows, then install Ethernet network controller. Then I was back in business. Overall Review: I have a Ryzen 3700X and everything worked right out of the box for the most part. just about 30 minutes of network and audio troubleshooting but its a nice board. I’m happy with it!

    Helpful(0) Unhelpful(0)You have already voted this
  2. Joseph G.

    Pros: Excellent performance for gaming Cons: Network adapter quite working after a week Having to send it back for replacement Overall Review: Great performance

    Helpful(0) Unhelpful(0)You have already voted this
  3. Anonymous

    Pros: Great manual with lots of useful info. Make sure to edit the frequency of your RAM and enable XMP mode if needed. BIOS is also good (coming from Gigabyte). RBG logo also looks good in the rig. It feel durable, but make sure to hold the back when you apply the pressure with the PSU cords. Cons: None Overall Review: It is worth the great money. Do not go cheap on Motherboard.

    Helpful(0) Unhelpful(0)You have already voted this
  4. Anonymous

    Pros: This board has many excellent features, but the LAN controller was bad on 2 boards in a row, after newegg exchanged it, and Asus acknowledges the issue. I still give NewEgg high marks for helping me with the exchange process, but it’s been frustrating waiting for a good board, since the 2nd one is now at the Asus repair facility on RMA. I’m still a strong proponent of Asus motherboards from my previous experiences, but I just got unlucky with this one. Cons: See above. Overall Review:…

    Helpful(0) Unhelpful(0)You have already voted this
  5. Brendan B.

    Cons: it won’t even connect to the ethernet i have plugged in and i know it works because i was just using it before putting the board in this is really annoying Overall Review: trash so far

    Helpful(0) Unhelpful(0)You have already voted this
  6. bubble

    Pros: -Sturdy board, easy build, enjoy the LEDS Cons: -Serious issues with the internet. Frequent pack loss / ping spikes for 2-5 seconds in multiplayer games. After spending a lot of time troubleshooting, I can only conclude that I am suffering from the same issue alluded to in many other reviews. A real shame to have this level of problem in an expensive product, especially from a normally quality brand. Overall Review: -Would not recommend due to issues with internet connectivity.

    Helpful(0) Unhelpful(0)You have already voted this
  7. Jeffrey G.

    Pros: Good solid board. It was easy to replace my old Intel MB with this and a Ryzen 5 5600x. I would have bought a cheaper B550 model, as I don’t care much about all the high-end gamer hoo-ha, but I wanted the Instant Flash button so I would be able to update the board even if it came with older BIOS not supporting ZEN 3. Cons: I have not been able to get the onboard 2.5GB NIC to connect at any speed except 100 megabits. So far I have had to install a separate Intel NIC card to get gigabit…

    Helpful(0) Unhelpful(0)You have already voted this
  8. Jason J.

    Pros: They were listed already but the cons and other information is where I’ve updated.. Cons: LAN controller having issues with speed and connectivity (got it working/stable after several Windows 10 reinstalls and several drivers the best being intel’s own driver.. Still flaky). On board NVME connectors eat/destroy/cause SSDs on the QVL list to suddenly stop working/cease to be seen/die. Overall Review: Like others, I’ve experienced the LAN issues after a few months. It took several…

    Helpful(0) Unhelpful(0)You have already voted this
