ASUS Prime Z690-P

$129.99

(3 customer reviews)
Last updated on August 16, 2025 12:26 am
0
Add to compare

Highest Price
$277.45 Newegg.com
March 4, 2025
Lowest Price
$129.99 Amazon.com
April 17, 2025
Current Price
$129.99 Amazon.com
August 16, 2025
Since March 4, 2025
This site uses affiliate links. We may earn a commission at no cost to you.
Prices and details are subject to change; check the seller’s site for updates.

Didn't find the right price? Set price alert below

Set Alert for Product: ASUS Prime Z690-P WiFi D4 LGA1700(Intel 12th Gen) ATX Motherboard (PCIe 5.0,DDR4,14+1 Power Stages,3X M.2,WiFi 6,BT v5.2,2.5Gb LAN,Front Panel USB 3.2 Gen 1 USB Type-Thunderbolt 4 Port,Arua Sync) - $129.99

Specification: ASUS Prime Z690-P

Product
Brand

Model

PRIME Z690-P

Product Type

Intel

Specification
Form Factor

ATX

Intel Optane Ready

Yes

Audio Channels

7.1 Channels

LAN Chipset

Realtek 2.5Gb Ethernet

Max LAN Speed

10/100/1000/2500Mbps

Back IO Ports

1 x USB 3.2 Gen 2×2 port (1 x USB Type-C)1 x USB 3.2 Gen 2 port (1 x Type-A)2 x USB 3.2 Gen 1 ports (2 x Type-A)2 x USB 2.0 ports (2 x Type-A) 1 x DisplayPort1 x HDMI port1 x Realtek 2.5Gb Ethernet port5 x Audio jacks1 x Optical S/PDIF out port1 x PS/2 Keyboard/Mouse combo port

Onboard USB

1 x USB 3.2 Gen 1 connector (supports USB Type-C) 2 x USB 3.2 Gen 1 headers support additional 4 USB 3.2 Gen 1 ports2 x USB 2.0 headers support additional 4 USB 2.0 ports

SATA 6Gbs

4 x SATA 6Gb/s

Other Connectors

Fan and Cooling related 1 x 4-pin CPU Fan header1 x 4-pin CPU OPT Fan header1 x 4-pin AIO Pump header3 x 4-pin Chassis Fan headersMiscellaneous3 x Addressable Gen 2 headers2 x AURA RGB headers1 x Clear CMOS header1 x COM Port header1 x Front Panel Audio header (AAFP) 1 x SPI TPM header (14-1pin)1 x 20-5pin System Panel header1 x Thunderbolt header

LED Lighting

RGB

Dimensions W x L

12.0" x 9.2"

Power Pin

1 x 24-pin Main Power connector1 x 8-pin +12V Power connector1 x 4-pin +12V Power connector

Windows 11

Ready

Features

Special Features:ASUS 5X PROTECTION III- DIGI+ VRM (- Digital power design with DrMOS)- LANGuard – Overvoltage Protection- SafeSlot- Stainless-Steel Back I/OASUS Q-Design – Q-DIMM- Q-SlotASUS Thermal Solution- Flexible M.2 heatsink – VRM heatsink designASUS EZ DIY- ProCoolAURA Sync- AURA RGB headers- Addressable Gen 2 RGB headersSoftware Features:ASUS Exclusive SoftwareArmoury Crate- AURA Sync- Fan Xpert 4 AI Suite 3- Performance And Power Saving UtilityTurboV EVOEPU DIGI+ VRMASUS CPU-ZNorton Anti-virus software (Free Trial version) WinRARUEFI BIOSASUS EZ DIY – ASUS CrashFree BIOS 3 – ASUS EZ Flash 3 – ASUS UEFI BIOS EZ ModeBIOS:192 (128+64) Mb Flash ROM, UEFI AMI BIOSManageability:WOL by PME, PXE Operating System:Windows 11 64-bit, Windows 10 64-bit

Package Contents

Accessories:Cables2 x SATA 6Gb/s cables Miscellaneous1 x I/O Shield 1 x M.2 Rubber Package2 x M.2 SSD screw packagesInstallation Media1 x Support DVDDocumentation1 x User guide

M.2

Intel 12th Gen Processors:M.2_1 slot (Key M), type 2242/2260/2280/22110- Intel 12th Gen processors support PCIe 4.0 x4 mode.Intel Z690 Chipset:**M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 & SATA modes)* Intel Rapid Storage Technology supports NVMe RAID 0/1/5, SATA RAID 0/1/5/10.** Intel Rapid Storage Technology supports Intel Optane Memory H Series on PCH attached M.2 slots.

Number of Memory Slots

4x288pin (DDR5)

Other Slots

V-M.2 slot only (Key E, CNVi & PCIe)** Wi-Fi module and vertical M.2 Key E bracket set are purchased separately.

PCI Express x1

1 x PCIe 3.0 x1

PCI Express 3.0 x16

2 x PCI Express 3.0 x16* Support x4 mode.

PCI Express 4.0 x16

1 x PCI Express 4.0 x16* Supports x4 mode.

PCI Express 5.0 x16

1 x PCI Express 5.0 x16* Actual support may vary by CPU.* Please check PCIe bifurcation table in support site.

Channel Supported

Dual Channel

Memory Standard

4800* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists)., 5000(OC), 5200(OC), 5400(OC), 5600(OC), 5800(OC), DDR5 6000(OC)

Onboard Video Chipset

Supported only by CPU with integrated graphic

Chipset

Intel Z690

Supported CPU Technologies

Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0** Intel Turbo Boost Max Technology 3.0 support depends on the CPU types.

Part Number

90MB19Q0-M0AAY0

Date First Available

January 25, 2022

Max Memory Supported

128GB

CPU Socket

LGA 1700* Designed with dual mounting holes compatible with both Intel LGA1700 and LGA1200 cooling brackets.

CPU Support

Celeron (12th Gen, Core, LGA1700), Pentium

Photos: ASUS Prime Z690-P

3 reviews for ASUS Prime Z690-P

3.3 out of 5
1
1
0
0
1
Write a review
Show all Most Helpful Highest Rating Lowest Rating
  1. Neuronscream

    Pros: Newegg as always was awesome to work with even though this is a manufacturer issue. They took care of me! This is why I’m a repeat customer time and time again. They’ve never let me down. Cons: There are serious memory issues with this board. Asus is up-reving the BIOS like nuts trying to tease out the bugs but unless you like frustration, I’d wait a while before picking one up. Supported memory doesn’t mean you’re going to have a functional system when you’re done. If you can’t POST…

    Helpful(0) Unhelpful(0)You have already voted this
  2. LIKE R.

    Pros: Pros: Price, features. More specifically Pcie5, DDR5, CPU M.2 above GPU slot, 2 more chipset M.2s, Pcie3x4 and Pcie3x1 far enough away from GPU slot to allow plenty of space for a 3 slot air cooler. The power delivery is more than adequate for what you can air cool (My Noctua NH D15 hits it’s limit at about 240w and I don’t think it is too far from top of the line air cooling) and the heatsinks for that are more than adequate as well. My low end Micron 4800c40 2x16GB overclocks to…

    Helpful(0) Unhelpful(0)You have already voted this
  3. Richard W.

    Pros: Good build quality very straight forward Cons: Tries to install pretty offensive bloatware Few USB plugs and headers Overall Review: Only took off 1 star for trying to auto install “Armory Crate.” The intrusion can be disabled in BIOS, but I shouldn’t have to do that. The aforementioned software would make this board more like a 2 egg if I had to use it. Luckily ASUS does have a pretty well made BIOS so it isn’t necessary for tweaking. Great deal for a DDR5 board overall.

    Helpful(0) Unhelpful(0)You have already voted this
